| Check Engine |
 |
This indicator appears if a fault occurs. Do not operate the
vehicle if this warning appears. Serious engine damage could result.
Your authorized POLARIS dealer can assist. |
| EPS Warning (if equipped) |
 |
This indicator illuminates when a fault has occurred in the
EPS system. Your authorized POLARIS dealer can assist. EPS operation
is possible with key on/engine off for up to 5 minutes. |
| Engine Hot |
 |
This lamp illuminates to indicate an overheated engine. If
the indicator flashes, a severe overheating condition exists. |
| Neutral |
 |
This lamp illuminates when the transmission is in neutral and
the ignition key is in the ON position. |
| Helmet/Seat Belt |
 |
This lamp flashes for several seconds when the key is turned
to the ON position. The lamp is a reminder to wear helmet and seat
belt (if equipped) before operating. |
| High Beam |
 |
This lamp illuminates when the headlamp switch is set to high
beam. |
| Brake Failure (if equipped) |
 |
Lamp illuminates when Brake System (if Brake Failure Alarm
is equipped) detects low fluid level in brake hydraulic system. Verify
brake fluid in reservoir. |
