Load/Passenger/Tire Pressure Alert
Never carry passengers in cargo box. Passengers can be thrown off. This can cause serious injury or death. Read owner's manual. NEVER carry fuel or other flammable liquids on this vehicle. Failure to follow this instruction could lead to serious burn injuries or death.
| RANGER XP KINETIC | |
| MAXIMUM CARGO BOX LOAD |
567 kg |
| TIRE PRESSURE IN kPa (bar) |
FRONT 83 (0,83) REAR 83 (0,83) |
|
TIRE PRESSURE WITH FULL LOAD (MAX CARGO + PASSENGER) IN kPa (bar) |
FRONT 97 (0,97) REAR 230 (2,3) |
|
MAXIMUM WEIGHT CAPACITY INCLUDES WEIGHT OF OPERATOR, PASSENGER, CARGO AND ACCESSORIES |
677 kg |
|
Read Operation and Maintenance Manual for more detailed loading information. |
|
