| Check Engine |
 |
This indicator appears if a fault occurs. Do not operate the
vehicle if this warning appears. Serious engine damage could result.
Your authorized POLARIS dealer can assist. |
| EPS Warning (if equipped) |
 |
This indicator illuminates when a fault has occurred in the
EPS system. Your authorized POLARIS dealer can assist. EPS operation
is possible with key on/engine off for up to 5 minutes. |
| Engine Hot |
 |
This lamp illuminates to indicate an overheated engine. If
the indicator flashes, a severe overheating condition exists. |
| Neutral |
 |
This lamp illuminates when the transmission is in neutral and
the ignition key is in the ON position. |
| Helmet/Seat Belt |
 |
This lamp is a reminder to the operator to ensure all riders
are wearing helmets and seat belts before operating. The driver’s
seat belt is equipped with a seat belt interlock. Vehicle speed will
be limited to 15 MPH (24 km/h) if the seat belt is not secured. |
| High Beam |
 |
This lamp illuminates when the headlamp switch is set to high
beam. |
| Brake Failure (if equipped) |
 |
Lamp illuminates when Brake System (if Brake Failure Alarm
is equipped) detects low fluid level in brake hydraulic system. Verify
brake fluid in reservoir. |
| Turn Signals |
 |
One arrow flashes when the corresponding turn signal is activated.
Both arrows flash when the hazard signal is activated. If there
is a problem in the signal system, the lamps will flash at twice the
normal rate. |
| Trailer Indicator (if equipped) |
 |
Lamp illuminates when trailer turn signals are active. |
