IMPORTANT

The Owner's Manual for this vehicle contains warnings, instructions and other information you must read and fully understand before safely riding or performing maintenance on this vehicle. Always follow the warnings and instructions in Owner's Manual.

Click the link above for the Table Of Contents, or download a full PDF of the Owner Manual in the Owner Support area of Polaris.com.

Indicator Lamps

Indicator Icon Function
Check Engine This indicator appears if a fault occurs. Do not operate the vehicle if this warning appears. Serious engine damage could result. Your authorized POLARIS dealer can assist.
EPS Warning (if equipped) This indicator illuminates when a fault has occurred in the EPS system. Your authorized POLARIS dealer can assist. EPS operation is possible with key on/engine off for up to 5 minutes.
Engine Hot This lamp illuminates to indicate an overheated engine. If the indicator flashes, a severe overheating condition exists.
Neutral This lamp illuminates when the transmission is in neutral and the ignition key is in the ON position.
Helmet/Seat Belt This lamp flashes for several seconds when the key is turned to the ON position. The lamp is a reminder to wear helmet and seat belt (if equipped) before operating. Vehicle speed will be limited to 15 MPH (24 km/h) if the seat belt is not secured.
High Beam This lamp illuminates when the headlamp switch is set to high beam.
Chassis Fault If applicable.
Speed Key (optional accessory) Information about the speed key is provided in the accessory kit.
Parent topic: Instrument Cluster
