Load/Passenger/Tire Pressure Alert

WARNING
-
Never carry passenger in cargo box.
-
NEVER carry fuel or other flammable liquids on this vehicle. Failure to follow this instruction could lead to serious burn injuries or death.
-
Read owner’s manual.
WARNING
IMPROPER TIRE PRESSURE OR OVERLOADING CAN CAUSE LOSS OF CONTROL RESULTING IN SERIOUS INJURY OR DEATH.
-
Reduce speed and allow greater distance for braking when carrying cargo.
-
Overloading or carrying tall, off-center, or unsecured loads will increase your risk of losing control. Loads should be centered and carried as low as possible in box.
-
For stability on rough or hilly terrain, reduce speed and cargo.
RANGER | RANGER 150 |
---|---|
MAXIMUM CARGO BOX LOAD |
23 kg (50 lbs) |
TIRE PRESSURE IN PSI (KPa) |
FRONT 5 psi (34.4 kPa) REAR 5 psi (34.4 kPa) |
MAXIMUM WEIGHT CAPACITY INCLUDES WEIGHT OF OPERATOR, PASSENGER, CARGO, AND ACCESSORIES. |
170 kg (375 lbs) |
Read Operation & Maintenance Manual for more detailed loading information. |
