Indicator
|
Icon
|
Function
|
| Check Engine |
|
This lamp illuminates when the ECM detects a Diagnostic Trouble
Code in the engine management system. Do not operate the vehicle if
this warning appears. Serious engine damage could result. Your authorized
POLARIS dealer can assist. This lamp will also illuminate if the vehicle
is keyed on but not started; it will turn off once the vehicle is
started. |
| EPS Warning (if equipped) |
|
This lamp illuminates to indicate that EPS has shut down. EPS
shuts down automatically 5 minutes after the engine is turned off
if the key remains in the ON position. Turn the key off and on to
reset the unit. If the light remains on after starting the engine,
the EPS system is inoperative. Your POLARIS dealer can assist. |
| Engine Hot |
|
This lamp illuminates to indicate an overheated engine. If
the indicator flashes, a severe overheating condition exists and the
engine will shut down automatically. The vehicle will not start again
until the engine has sufficiently cooled down. Whenever this lamp
illuminates, the engine load should be reduced in any way possible
to avoid overheating and shutting down the engine. |
| Low Oil Pressure |
|
This lamp illuminates if engine oil pressure
drops below safe operating pressure. If this lamp illuminates while
the engine is running, turn the engine off as soon as safely possible
and check the oil level. If the oil level is correct and the lamp
remains on after the engine is restarted, turn the engine off immediately.
|
| Helmet/Seat Belt |
|
This lamp flashes for several seconds when the key is turned
to the ON position. The lamp will keep flashing as long as riders’
seat belts are not connected. |
| High Beam |
|
This lamp illuminates when the headlamp switch is set to high
beam. |
| Park Brake Indicator |
|
This lamp illuminates when the park brake is
active. |
| Glow Plug Indicator |
|
This lamp illuminates when the glow plugs are
active. |
