Indicator Lamps

Lamp Indicates Condition
Vehicle Speed When standard mode is selected, speed displays in miles per hour.
When metric mode is selected, speed displays in kilometers per hour.
Turn Signal / Hazard Signals The turn signals are located at the top center of the instrument cluster. Arrows flash when either a turn signal or the hazard signal is activated. If a lamp fails, or if there is a short circuit in the signal system, the lamp flashes at more than twice the normal rate.
Low Battery Voltage This lamp illuminates when battery voltage is low (or when voltage is above the normal range). Turn non-essential accessories off to conserve power. Make sure the charging system is operating properly.
Over Temperature This lamp illuminates to indicate an overheated engine. If the indicator flashes, the overheating condition remains, and the system will automatically reduce engine power.
EPS Warning (if equipped) This indicator illuminates briefly when the key is turned to the ON position. If the light remains on, the EPS system is inoperative. See your POLARIS dealer, or other qualified person, as soon as possible for repair. Continued operation could result in permanent damage to the EPS unit and increased steering effort.
Chassis Warning If a fault condition is detected, the light will remain on as long as the condition exists. Retrieve the error codes for diagnosis. This lamp is also known as an Amber Warning Lamp (AWL).
Check Engine If this lamp illuminates while the engine is running, promptly contact an authorized dealer or another qualified person who can assist with diagnosis. If abnormal engine operation is detected the light will remain on as long as the fault condition exists. Retrieve the error codes for diagnosis. See the Error Codes section for details. This lamp is also known as a malfunction indicator lamp (MIL).
Seat Belt The seat belt lamp illuminates whenever the vehicle is in ignition state and the driver’s seat belt is not fastened. The driver’s seat belt is equipped with a seat belt interlock. Vehicle speed will be limited to 15 MPH (24 km/h) if the seat belt is not secured.
High Beam This lamp illuminates when the headlamp switch is set to high beam.
Low Fuel This lamp illuminates when approximately one gallon (3.8 liters) of fuel remains in the fuel tank.
Trailer Indicator The Turn Trailer Indicator is illuminating when the trailer turn signals are active.
Brake Failure This lamp illuminates when the brake system (if Brake Failure Alarm is equipped) detects low fluid level in main brake hydraulic system. Verify brake fluid in main reservoir at the front of the vehicle. Low brake fluid leads to a possibility of braking failure.

The vehicle may have brake failure when the Brake Failure lamp is on and

  • brake lights are always on, or

  • vehicle has limited power, or

  • vehicle does not respond to the gas pedal in P and N gears - the engine only idles.

Brake failure damage can be minimized by limiting the torque.

Once brake fluid has been added, turn the vehicle on and off to clear the Brake Failure lamp.
PASS (PIN Activated Security System, if equipped) The security indicator lamp illuminates when the security system is enabled.
Cruise Control Engaged (if equipped) Before using the cruise control, read the safety and operation procedures.
Performance Limited (if equipped) Not applicable.
