IMPORTANT

The Owner's Manual for this vehicle contains warnings, instructions and other information you must read and fully understand before safely riding or performing maintenance on this vehicle. Always follow the warnings and instructions in Owner's Manual.

Click the link above for the Table Of Contents, or download a full PDF of the Owner Manual in the Owner Support area of Polaris.com.

Israel Model Differences

IMPORTANT
Israel models are significantly different from other models covered by this owner’s manual. The unique characteristics of Israel models will not be referenced throughout the rest of this owner’s manual. If you are using an Israel model, carefully read the statements below and bear them in mind before consulting the rest of the owner’s manual.

ISRAEL MODELS ARE TWO-PERSON VEHICLES.

Israel models are designed to accommodate two individuals - a driver and a passenger. Do not operate Israel models with more than one passenger, as only two seat belts are available for use. If you are using an Israel model, disregard all other mentions of “passengers” within the manual text.

DECLARATION OF CONFORMITY NOTE

The “Declaration of Conformity” section (in the Introduction chapter) does not apply to Israel models. Disregard the “Declaration of Conformity” section if you are using an Israel model.

ISRAEL MODELS ARE ON-ROAD VEHICLES.

Israel models are certified for on-road use in your region. Disregard warnings prohibiting on-road use in the manual text if you are using an Israel model.

General Alert

The General Alert is located on the console.

WARNING

Read the owner’s manual. Never allow anyone under 16 years of age to operate this vehicle. Never use alcohol or drugs before or while driving or riding. This vehicle is approved for on-road operation. Wear approved helmet, goggles, and protective clothing. Always wear seat belts. Always use the cab nets or doors. Avoid aggressive driving maneuvers that may cause vehicle tipping or rollover.

Clutch Cover Alert

The Clutch Cover Alert decal is located on the clutch cover.
CAUTION
Read your owner’s manual. Keep body parts away from belt.

Intake Alert

The Intake Alert Caution label is located on the air intake.
CAUTION
Use a Polaris approved air filter. The use of a non-Polaris approved air filter may cause engine damage. Before installing filter ensure there is no dirt or debris in the clean side of the intake tube. The air filter must be properly seated and the hinges fully inserted when the lid is reinstalled. Please reference your owner’s manual for additional information regarding the air filter service.

Hitch Capacity Alert

The Hitch Capacity Alert is located on the hitch receiver.
WARNING

  • Read the owner’s manual.

  • MAXIMUM DRAWBAR PULL: 3200 N ON LEVEL GROUND

  • MAXIMUM VERTICAL LOAD: 1700 N

Load / Passenger / Tire Pressure Alert

The Load/Passenger/Tire Pressure Alert is located on the cargo box.

WARNING
Never carry passengers in cargo box. Passengers can be thrown off. This can cause serious injury or death. Read owner's manual. Carrying fuel or other flammable liquids on this vehicle unless could lead to serious burn injuries or death. Only carry fuel using a POLARIS-approved Portable Fuel Container and Mount, and follow the instructions that come with the container and mount.

RANGER
MAXIMUM CARGO BOX LOAD

454 kg
TIRE PRESSURE IN kPa (bar, PSI)

FRONT 83 (0,83, 12 )

REAR 97 (0,97, 14)

Read Operation and Maintenance Manual for more detailed loading information.
RANGER CABBED
MAXIMUM CARGO BOX LOAD

390 kg
TIRE PRESSURE IN kPa (bar, PSI)

FRONT 83 (0,83, 12 )

REAR 97 (0,97, 14)

Read Operation and Maintenance Manual for more detailed loading information.

Part number: 7301360
