Studs

NOTICE

Failure to heed the following recommendations will result in tunnel or track damage and a voided warranty.

Track damage resulting from improperly installed or maintained studs is not covered under warranty. Use only POLARIS-approved traction products on your snowmobile. See your dealer for more information about installing studs and/or carbides.

NOTICE

Use of studs longer than the recommended length on snowmobiles equipped with center coolers will result in center cooler damage or damage to the tunnel.

NOTICE

Do not install studs on this snowmobile unless the proper stud protection kits have been installed or damage will occur.

The Matryx chassis requires a stud protection kit to be installed before installing studs or chassis damage will occur. This stud protection kit will protect against chassis damage with the following track/stud combinations.

Chassis/Track Stud Protection Kit
Matryx 129 / Storm 150 PN: 2884961
Matryx 137 / Cobra / Ice Ripper PN: 2884962
Matryx 146 / Cobra 1.3 PN: 2884963
Matryx 155 PN: 2891520

  • 1.325 in Polaris/Woody’s® studs installed in a Ripsaw II 1.25 in or Cobra 1.325 in track.

  • 1.575 in Polaris/Woody’s® studs installed in a Storm 150 track, center band only.

  • 1.575 in Polaris/Woody’s® studs installed in a Cobra 1.6 in track.

  • 1 Penetration Range 1/4 - 3/8 in (6-9 mm)

  • 2 Stud Size

  • 3 Track Lug Height

  • 4 Track Belt Thickness
