Indicator Lamps
| Indicator | Icon | Function |
|---|---|---|
|
Check Engine |
 |
This indicator appears if a fault occurs. Do not operate the vehicle if this warning appears. Serious engine damage could result. Your authorized Polaris dealer can assist. |
|
EPS Warning (if equipped) |
 |
This indicator illuminates when a fault has occurred in the EPS system. Your authorized Polaris dealer can assist. |
|
Engine Hot |
 |
This lamp illuminates to indicate an overheated engine of at least (111 c). If the indicator flashes, a severe overheating condition exists. Engine shut down will occur at (119 c). |
|
Neutral |
 |
This lamp illuminates when the transmission is in neutral and the ignition key is in the ON position. |
|
Helmet/Seat Belt |
 |
This lamp flashes for several seconds when the key is turned to the ON position. The lamp is a reminder to wear helmet and seat belt (if equipped) before operating. |
|
High Beam |
 |
This lamp illuminates when the headlamp switch is set to high beam. |
|
Brake Failure |
 |
This lamp illuminates when the Brake System detects a stuck brake while the throttle lever is engaged. This lamp also illuminates when the brake fluid level in the rear brake circuit is too low. Stop the vehicle, check the brake functionality, and verify the brake fluid in the reservoirs. |
|
Trailer Indicator |
 |
The Turn Trailer Indicator is illuminating when the trailer turn signals are active. |
|
Turn Signals |
 |
One arrow flashes when the corresponding turn signal is activated. Both arrows flash when the hazard signal is activated. If there is a problem in the signal system, the lamps will flash at twice the normal rate. |
